产品规格
- 512MB, 1GB
- SLC type
- Industrial Grade
- Operation Temperature: -40 ~ +85°C
Specifications
IDE Transfer Mode PIO Mode 0-6 / MDMA Mode 4 / Ultra DMA Mode-6
Drive Config. Switch Master/Slave
Data Transfer Rate Read 30 Mbytes(Max)/sec
Write 7 Mbytes(Max)/sec
Bus Interface ATA Compatibility
Flash Type SLC
Connector 44pin IDE/ATA ANSI Standards
Storage Capacity 512MB / 1GB
Sector Size 512 bytes
Drive Number Drive 0 or 1
Operation Temp. ℃ ℃-40 ~+85
Storage Temp. ℃ ℃-40 ~+125
Humidity 10%~95% non-condensing
Vibration 1G (5~500Hz)
Shock 30G/11ms
ECC Technology High Reliability based on the internal ECC function
MTBF >3,000,000 hours
R/W Endurance 100,000 times
Wear-leveling Support
Data Integrity 10 years
DC Input Voltage +3.3V / +5V single power supply operation
Power Mode Auto Stand-by and sleep mode
Power Consumption 250mA (max.)
Dimension 48 x 32.6 x 6.2 mm (W x L x H)
Ordering Information
PART NO. Capacities Type Operation Temp.
DDOM-MN-512M-44P-HL 512MB Horizontal Right ℃ ℃-40 ~+85
DDOM-MN-512M-44P-H 512MB Horizontal Left ℃ ℃-40 ~+85
DDOM-MN-1G-44P-HL 1GB Horizontal Right ℃ ℃-40 ~+85
DDOM-MN-1G-44P-H 1GB Horizontal Left ℃ ℃
