产品规格
- 1GB
- SLC type
- Industrial Grade
- Operation Temperature: -40 ~ +85°C
Specifications
IDE Transfer Mode PIO Mode 0-6 / MwDMA Mode 4 / Ultra DMA Mode 0~4
Drive Config. Switch Master/Slave
Data Transfer Rate Read 30 Mbytes(Max)/sec
Write 20 Mbytes(Max)/sec
Bus Interface ATA Compatibility
Flash Type SLC
Connector 44pin IDE/ATA ANSI Standards
Storage Capacity 1GB
Sector Size 512 bytes
Drive Number Drive 0 or 1
Operation Temp. ℃ ℃-40 ~+85
Storage Temp. ℃ ℃-65 ~+150
Humidity 10%~95% non-condensing
Vibration 5G (7~2000Hz)
Shock 50G/10ms
ECC Technology High Reliability based on the internal ECC function
MTBF >3,000,000 hours
R/W Endurance 2,000,000 times
Wear-leveling Support
Data Integrity 10 years
DC Input Voltage +3.3V / +5V single power supply operation
Power Mode Auto Stand-by and sleep mode
Power Consumption 150mA (max.)
Dimension 48 x 32.6 mm (W*L)
Ordering Information
PART NO. Capacities Type Operation Temp.
DDOM-SST-1G-44P-HL 1GB Horizontal Right ℃ ℃-40 ~+85
DDOM-SST-1G-44P-H 1GB Horizontal Left ℃ ℃-40 ~+85
DDOM-SST-1G-44P-V 1GB Vertical ℃ ℃-40 ~+85
